Bus-Bar electric terminal board

High insulating capacity plastic base; nickel-plated cooper support bar, stainless steel screws and nuts. Volt 12/48.

Master items

Item
Shunt terminal mm
Power terminal mm
Base mm
A continuous capacity
Cover
* Price

-
4x5
107x22
100
PZ
Order Quantity
5x4
2x5
107x22
100
PZ
Order Quantity
10x4
2x6
145x31
150
PZ
Order Quantity
20x4
2x6
225x31
150
PZ
Order Quantity
-
4x6
152x32
150
PZ
Order Quantity
-
6x6
230x32
150
PZ
Order Quantity
6x5
2x8
153x38
250
PZ
Order Quantity
12x5
2x8
201x38
250
PZ
Order Quantity
-
4x8
153x38
250
PZ
Order Quantity
-
4x8
201x38
250
PZ
Order Quantity
-
4x10
178x51
600
PZ
Order Quantity
-
8x10
289x51
600
PZ
Order Quantity

Find nearest store:
Bus-Bar cover 107 x 22 mm

14.208.04

Bus-Bar cover 107 x 22 mm

Bus-Bar cover 145 x 31 mm

14.208.10

Bus-Bar cover 145 x 31 mm

Bus-Bar cover 225 x 31 mm

14.208.20

Bus-Bar cover 225 x 31 mm

Bus-Bar cover 152 x 32 mm

14.208.24

Bus-Bar cover 152 x 32 mm

Bus-Bar cover 153 x 38 mm

14.208.25

Bus-Bar cover 153 x 38 mm

Bus-Bar cover 230 x 32 mm

14.208.26

Bus-Bar cover 230 x 32 mm

Bus-Bar cover 201 x 38 mm

14.208.30

Bus-Bar cover 201 x 38 mm

Bus-Bar cover 178 x 51 mm

14.208.31

Bus-Bar cover 178 x 51 mm

Bus-Bar cover 289 x 51 mm

14.208.32

Bus-Bar cover 289 x 51 mm
